Ductile Iron Casting Chassis Bracket For Heavy Truck Accessories
Product Details:
| Place of Origin: | China |
| Brand Name: | Twinkle Industrial |
| Certification: | ISO 9001 |
| Model Number: | TIICP-127 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 10 pcs |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Non-fumigation wooden box |
| Delivery Time: | 20 work days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 20000 pc per month |
|
Detail Information |
|||
| Product Name: | OEM Ductile Iron QT400 Iron Casting Parts For Engine Oil Nozzle | Application: | Engine Oil Nozzle |
|---|---|---|---|
| Material: | Ductile Iron | Package: | Wooden Box |
| Surface: | Red Painting | ||
| Highlight: | Heavy Truck Accessories Casting Chassis Bracket,Ductile Iron Casting Chassis Bracket |
||
Product Description
Ductile Iron Casting Chassis Bracket For Heavy Truck Accessories
Quick Detail:
· Ductile Iron Casting Chasis Bracket
· Ductile iron QT400, GGG40
· Sand Casting and CNC machining
· Shot Blasting and red painting
· Truck Engine or Automotive
| Ductile Iron Material Grade From TwinkleIndustrial in Different Countries | ||||||||
| No. | China/GB 699 | Russia/ROCT | USA/ASTM A536 | England/BS | France/NF | Germany/DIN | Japan/JIS | ISO 683/1 |
| 1 | QT400-18 | BЧ40 | 60-40-18 | 400/17 | FGS370-17 | GGG40 | FCD400 | 400-18 |
| 2 | QT450-10 | BЧ45 | 65-45-12 | 420/12 | FGS400-12 | FCD450 | 450-10 | |
| 3 | QT500-7 | BЧ50 | 70-50-05 | 500/7 | FGS500-7 | GGG50 | FCD500 | 500-7 |
| 4 | QT600-3 | BЧ60 | 80-60-03 | 600/7 | FGS600-2 | GGG60 | FCD600 | 600-3 |
| 5 | QT700-2 | BЧ70 | 100-70-03 | 700/2 | FGS700-2 | GGG70 | FCD700 | 700-2 |
| 6 | QT800-2 | BЧ80 | 120-90-02 | 800/2 | FGS800-2 | GGG80 | FCD800 | 800-2 |
| 7 | QT900-2 | BЧ90 | 900/22 | 900-2 | ||||
Product Description:
Ductile iron casting is commonly used in the manufacturing of chassis brackets for various applications, including automotive, heavy machinery, and industrial equipment. Chassis brackets serve as structural components that support and connect different parts of the chassis, providing stability and strength to the overall vehicle or machinery. Here are some key points about ductile iron casting for chassis brackets:
-
Material: Ductile iron, also known as nodular cast iron or spheroidal graphite iron, is a type of cast iron that exhibits improved mechanical properties compared to traditional gray iron. It contains graphite nodules within its microstructure, which provide enhanced ductility, toughness, and tensile strength.
-
Strength and Durability: Ductile iron offers high tensile strength and toughness, making it well-suited for chassis bracket applications. It provides the necessary structural integrity to withstand the mechanical stresses, loads, and impacts experienced by the chassis during operation.
-
Design Flexibility: Ductile iron casting allows for the production of chassis brackets with complex shapes and intricate designs. The casting process enables the creation of brackets with specific features, such as mounting holes, flanges, and reinforcement ribs, to accommodate the specific requirements of the chassis and its components.
-
Machinability: Ductile iron is known for its good machinability, allowing for precise machining and finishing of the chassis brackets. Machining operations, such as drilling, tapping, and milling, can be performed to achieve accurate dimensions and ensure proper fitment and alignment.
-
Corrosion Resistance: Ductile iron has good corrosion resistance, which is important for chassis brackets that are exposed to various environmental conditions. The surface of the ductile iron brackets can be further protected through coatings or treatments to enhance their corrosion resistance and prolong their service life.
-
Vibration Damping: Ductile iron possesses excellent vibration damping properties, reducing the transmission of vibrations and noise within the chassis. This helps improve the overall comfort and performance of the vehicle or machinery.
-
Weight: Ductile iron offers a favorable strength-to-weight ratio, providing sufficient strength while keeping the weight of the chassis brackets relatively low. This is particularly advantageous in applications where weight reduction is desired to enhance fuel efficiency or optimize the payload capacity of the equipment.
-
Cost-Effectiveness: Ductile iron casting is a cost-effective manufacturing process for chassis brackets, as it allows for the production of complex geometries in a single piece. This reduces the need for additional fabrication or assembly steps, resulting in overall cost savings.
Product Specifications:
| Commodity | Iron Casting & Machining Parts / Gear Cap |
| Standard | ASTM, DIN, JIS, EN, ISO, BS, JCSI, GB |
| Material | Grey iron (HT200,HT250,HT300), Ductile iron (QT400-18,QT400-15,QT450-10,QT500-7) |
| Unit Weight | 0,05 kg ~ 1,000 kg. |
| Tolerance | CT6-CT8 |
| Machining | Turning, Milling, Drilling, Cutting, Reaming, Threading, Welding, Tooling, etc |
| Surface Treatment | Shot blasting, Painting, Powder coating, Electroplating, Chrome plating, etc |
| Package | Standard wooden box package or as your customized package |
| Applications |
Agricultural machinery, Petroleum machinery, Mining machines, Construction, Automotive & Truck, Medical, Marine, Railway & Train, Power lines, Furniture, Lighting, Flange, Valve and Pump, Electronic, Pipeline, etc. |
| Brand | Twinkle Industrial |
Product Applications:
Widely used agricultural machinery, petroleum machinery, mining machines, construction, automotive & truck, medical, marine, railway & train, power lines, furniture, lighting, flange, valve and pump, electronic, pipeline, etc.
FAQ
Q1. How can we get a quotation?
A: Please send the parts 2D drawing (in PDF format) and 3D model in IGS or STP format together with material, production technique, purchasing qty, etc, or provide sample to us.
Q2. What about the lead time?
A: 15-20 days for Sample making ,20 working days for mass production.
Q3. Do you have any MOQ limit for casting parts?
A: It depends on different parts. For some parts, 1 pc can be acceptable.
Q4. What is your payment term?
A: Mold: 50% payment in advance, balance after the sample approval.
B: Mass production: 30% payment in advance, 70% balance before shipment.
Q5. What is your quality control process?
A: Each casting parts will be provided with raw material report ( chemical composition and physical property), and dimension measuring report before shipment.
Q6. How about the packaging?
A: Standard wooden box package or as your customized package.
